Specialised Mooring Monitoring for Pioneering Floating Offshore Wind Farm Project

Strainstall has been awarded a contract to provide crucial mooring monitoring for the Hywind pilot park – the world’s first floating offshore wind farm. The contract with MacGregor, a provider of innovative engineering solutions for handling marine cargoes and offshore loads, will provide an integrated offshore mooring solution for the floating turbines.

The Hywind pilot park off the coast of Peterhead, Scotland, being developed by Statoil, aims to demonstrate the feasibility of future commercial floating offshore wind farms in deepwater sites with optimal wind conditions. The site will consist of five, 6 MW floating turbines, with production of the first turbine expected in late 2017. And although a pilot project, the wind farm will be fully operational, powering around 20,000 households in Aberdeenshire.

Understanding how the structures will react within this challenging offshore environment is key to establishing Hywind’s feasibility, particularly in relation to how the mooring lines will perform with the demands placed upon them. Each floating turbine will be securely moored to the seabed via MacGregor’s unique chain stoppers which will incorporate Strainstall’s innovative and patented strain ring monitoring sensors to provide highly accurate mooring load information.

The highly accurate and extremely robust strain ring sensors fitted to MacGregor’s Pusnes chain stoppers, which make up the mooring monitoring system, can sense minute changes in tension enabling detailed understanding of the load and fatigue life of the floating structures, providing detailed insight for future design developments.

The mooring monitoring system will monitor the different stresses placed on the turbines that could affect the performance of the structures and the mooring lines. Large floating turbines induce vibrations due to the high winds and swell from the deepwater site in the North Sea, which is one of the toughest environments in the world. High winds will put additional stresses on the structures and mooring, so having a monitoring system to measure tension is crucial to the safe ongoing operation of the site.

 “We have worked with MacGregor for many years providing our unique strain ring product for their pusnes chain stopper mooring applications in the oil and gas industry and we are delighted to work with them to bring our combined technologies into the renewables sector for this world first project.” explained Simon Everett, managing director at Strainstall.

“Strainstall has considerable experience of providing mooring monitoring solutions and we see an exciting opportunity to bring this knowledge to the floating renewables market as it develops over the coming years” Everett concluded.
